NK R400

NK R400 — Industrial 5G RedCAP Wireless Router

The NetKonnekt NK R400 bridges the gap between legacy LTE deployments and the 5G era. Built on 3GPP Release 17 5G RedCAP (Reduced Capability) technology, it gives applications currently running on LTE Cat-1 or Cat-4 a direct migration path to 5G — lower latency and network slicing — without the power draw or cost of a full eMBB modem.

Key Features

• Snapdragon X35 Platform — Powered by the Qualcomm Snapdragon X35 5G Modem-RF System, the world’s first 5G RedCAP-optimized solution, for future-proof connectivity and superior power efficiency.

• Industrial-Grade Durability — Rugged extruded-aluminium metal housing provides EMI protection and superior heat dissipation for harsh industrial environments.

• Optimized MIMO Antenna System — Four high-gain external antennas (2× cellular, 2× WiFi) deliver stable 2×2 MIMO performance in high-interference or signal-fringe conditions.

• Flexible Network Architecture — A software-defined LAN0/WAN port plus a dedicated LAN1 port allow versatile integration into existing industrial Ethernet networks.

• At-a-Glance Diagnostics — Front-panel LED array (WPS, WiFi, Internet, Mobile) plus a 5-segment signal-strength bar for real-time hardware and RSRP visibility.

• Front-Access Serviceability — Push-push Nano SIM slot and recessed RESET/WPS buttons for safe cabinet-mount access.

Technical Highlights

• Cellular: 5G NR RedCAP (SA/NSA) + LTE, 3GPP Release 17
• 5G NR Bands: 26 total (n1–n79, incl. n1, n2, n3, n5, n7, n8, n12–n14, n18, n20, n25, n26, n28, n30, n38, n40, n41, n48, n53, n66, n70, n71, n77–n79)
• LTE Bands: 28 total (B1–B71)
• Antennas: 4× SMA — 2× cellular (2×2 MIMO), 2× WiFi (2×2 MIMO)
• Ports: 1× LAN1 (RJ45), 1× LAN0/WAN (RJ45, software-defined)
• Power: DC barrel jack, wide voltage input
• SIM: 1× front-facing Nano SIM, push-push
• Mounting: DIN-rail or wall-mount
• Environmental: −40°C to +75°C, 5–95% RH non-condensing

Built for B2B Industrial Environments

Smart manufacturing • Remote utility monitoring • Automated logistics
